3/4" ULTRA R16 by Couplamatic | Import Ultra Two Wire Hi-Pressure | High/Low Temp Hydraulic Hose | 100R16/DIN 2SC | 3/4" ID | 250ft
Couplamatic Systems Inc.
Two Wire Braid Hoses - ULTRA R16 Import Ultra Two Wire Hi-Pressure High/Low Temp Hydraulic Hose - ULTRA 100R16 / DIN 2SC
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 2–3 | $2,684.85 |
| 4–9 | $2,570.60 |
| 10+ | $2,284.98 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
3125
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, High/Low Temp Applications | SAE Rating: | ULTRA 100R16 / DIN 2SC |
|---|---|---|---|
| Cover: | Blue Abrasion and Flame Resistant Cover, MSHA approved | Reinforcement: | Two Wire Braids |
| Temperature: |
-58F to +275F (-50C to +135C) (+302F/150C Discontinuous) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" ULTRA R16 | 1/4" | 0.530" | 5,800 lbs. | 23,200 lbs. | 2" | 18 lbs. | 500ft |
| 3/8" ULTRA R16 | 3/8" | 0.687" | 5,000 lbs. | 20,000 lbs. | 2.5" | 27 lbs. | 400ft |
| 1/2" ULTRA R16 | 1/2" | 0.812" | 4,250 lbs. | 17,000 lbs. | 3.5" | 35 lbs. | 300ft |
| 5/8" ULTRA R16 | 5/8" | 0.937" | 3,625 lbs. | 14,500 lbs. | 4" | 40 lbs. | 250ft |
| 3/4" ULTRA R16 | 3/4" | 1.090" | 3,125 lbs. | 12,500 lbs. | 4.8" | 54 lbs. | 250ft |
| 1" ULTRA R16 | 1" | 1.405" | 2,500 lbs. | 10,000 lbs. | 6" | 74 lbs. | 200ft |
**Crimps to 100R1AT One Wire Thin Cover Specs - Tighter Bend Radius than R1 and R2 - High/Low Temp**
