3/4" 4SH - EN856 by Couplamatic | Four Spiral Extra High Pressure | Import Hydraulic Hose | 3/4" ID | 50ft Bulk Length
Couplamatic Systems Inc.
4 High Tensile Steel Spirals - 4SH Four Spiral Extra High Pressure Import Hydraulic Hose - 4SH (EN856)
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $437.09 |
| 15–29 | $395.24 |
| 30+ | $348.74 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
6090
Specifications and Approvals:
Compatible Series:
| Applications: | Very High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | N/A |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Black Cover, MSHA Approved, White Layline | Reinforcement: | 4 High Tensile Steel Spirals |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Coil Footage |
|---|---|---|---|---|---|---|---|
| 5/8" 4SH | 5/8" | 1.130" | 6,090 lbs. | 24,360 lbs. | 9.5" | 97 lbs. | Bulk |
| 3/4" 4SH | 3/4" | 1.268" | 6,090 lbs. | 24,360 lbs. | 11" | 112 lbs. | Bulk |
| 1" 4SH | 1" | 1.523" | 5,510 lbs. | 22,040 lbs. | 13.5" | 131 lbs. | Bulk |
| 1-1/4" 4SH | 1-1/4" | 1.791" | 5,075 lbs. | 20,300 lbs. | 18" | 181 lbs. | Bulk |
| 1-1/2" 4SH | 1-1/2" | 2.085" | 4,205 lbs. | 16,820 lbs. | 22" | 241 lbs. | Bulk |
