BS029 - #29 Beltservice 2 Ply 15 oz. CP 30 Black Nitrile COS Conveyor Belt

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
Assembly line Packaging All-purpose conveyor belts
Features:
All-purpose conveyor belts with smooth nitrile top covers for assembly line, packaging, and a wide variety of industrial uses. The 2 ply is made with a cotton-polyester blend carcass. Flexible, yet strong, the 3 ply features a heavier polyester carcass for added stretch resistance. Both belts have superior oil, grease, and animal fat resistance, and good heat capability.
Specifications:
FDA approved

	2 Ply CP 30 15 oz. Black Nitrile COS Pt No.: 29	3 Ply Poly 135 Black Nitrile COS Pt No.: 30
Thickness	3/32"	9/64"
Covers	3/64" x FS
Carcass	15 oz. C-P	45 lbs. per ply Polyester
Working Tension Per Inch Width	35 lbs.	135 lbs.
Approx. Weight Lbs. Per Inch Width	.059 lbs.	.077 lbs.
Min. Pulley Diameter	1-1/2"	2"
Temperature Range	0 deg. F / 250 deg. F
Clipper Lace	#1A	#1
Alligator Lace	#7	#15

COS = Cover One Side
