2600207 (07B) by PT-Coupling | Corrosion Resistant Cam & Groove Coupler | Type B | 3/4" Coupler x 3/4" Male NPT | Hastelloy | Buna-N Seal
Buy more, save moreDiscounts applied in cart/checkout.
| Features & Applications: | |||
|---|---|---|---|
|
 |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Part Name |
Item # | Coupler Size |
Male NPT Thread |
O. D. with Cam Arms Extended (A) |
Outside Diameter (B) |
Overall Length (C) |
Exposed Length (D) |
Inside Diameter (E) |
Max. Allowable Working Press. (PSI)* |
| 07B | 2600207 | 3/4" | 3/4" | 4.51" | 2.11" | 2.10" | 1.25" | 0.78" | 250 PSI |
| 10B | 2600210 | 1" | 1" | 5.10" | 2.44" | 2.50" | 1.56" | 0.97" | 250 PSI |
| 15B | 2600215 | 1-1/2" | 1-1/2" | 7.16" | 3.56" | 2.93" | 1.88" | 1.50" | 250 PSI |
| 20B | 2600220 | 2" | 2" | 7.54" | 3.94" | 3.20" | 2.15" | 1.88" | 250 PSI |
| 30B | 2600230 | 3" | 3" | 9.56" | 5.46" | 3.82" | 2.27" | 2.88" | 200 PSI |
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
Additional Product Data:
Shape:
Straight
Cam & Groove Type:
Type B
Ends Configuration:
Material(s):
Seal Material(s):
