BS025 - #25 Beltservice 5 Ply Brown Nitrile FBS Conveyor Belt

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
Power transmission belting Metal parts Tapes for folding machines
Features:
Features a tightly woven blend of cotton and polyester plies impregnated with nitrile, producing a belt suitable for light and medium-weight conveying for a multitude of applications. Particularly popular for oily conditions, especially the conveying of metal parts, also as carrying tapes for folding machines. Commonly used for power transmission belting in the heavier weights for conditions involving oil and heat. Economical Very flexible

	3 Ply Brown Nitrile FBS Pt No.: 24	5 Ply Brown Nitrile FBS Pt No.: 25	7 Ply Brown Nitrile FBS Pt No.: 26	9 Ply Brown Nitrile FBS Pt No.: 26a
Thickness	1/16"	7/64"	5/32"	13/64"
Covers	FBS
Carcass	8.1 oz. Cotton-Polyester Blend
Working Tension Per Inch Width	36 lbs.	60 lbs.	84 lbs.	108 lbs.
Approx. Weight Lbs. Per Inch Width	.037 lbs.	.065 lbs.	.094 lbs.	.121 lbs.
Min. Pulley Diameter	3/4"	1-1/2"	3"	4"
Temperature Range	0 deg. F / 250 deg. F
Clipper Lace	#1D	#1A	#2	#3
Alligator Lace	#00	#7	#20	#27

FBS = Friction Both Sides
