2200210 (10B) by PT-Coupling | Corrosion Resistant Cam & Groove Coupler | Type B | 1" Coupler x 1" Male NPT | Monel | Buna-N Seal
PT Coupling
Corrosion Resistant Cam & Groove (Camlock) Adapter | Type B | Coupler x Male NPT | Monel | Buna-N Seal
These corrosion resistant cam & groove couplings are designed for acid applications in highly corrosive media including hydrochloric acid and sulfuric acid.
Made in the USA
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $130.45 |
| 20–59 | $117.96 |
| 60+ | $104.09 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Cam & Groove Type:
Type B
Ends Configuration:
Material(s):
Seal Material(s):
| Features & Applications: | |||
|---|---|---|---|
|
 |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Part Name |
Item # | Coupler Size |
Male NPT Thread |
O. D. with Cam Arms Extended (A) |
Outside Diameter (B) |
Overall Length (C) |
Exposed Length (D) |
Inside Diameter (E) |
Max. Allowable Working Press. (PSI)* |
| 10B | 2200210 | 1" | 1" | 5.10" | 2.44" | 2.50" | 1.56" | 0.97" | 250 PSI |
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
