2000160 (60A) by PT-Coupling | Cam & Groove Adapter | Type A | 6" Adapter x 6" Female NPT | Hard Coat Aluminum

2000160 (60A) by PT-Coupling | Cam & Groove Adapter | Type A | 6" Adapter x 6" Female NPT | Hard Coat Aluminum

Sale price$174.60

PT Coupling
Cam and Groove (Camlock) Adapter | Type A | Adapter x Female NPT Thread | Hard Coat Aluminum

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Buy More, Save More!
Quantity Price Each
5–19 $164.12
20–59 $148.41
60+ $130.95
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Cam & Groove Type:

Type A

Ends Configuration:
  • 6in Male Cam & Groove
  • 6in Female NPT
Overview:
  • PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
  • This is a lightweight material with good abrasion resistance. Good corrosion and chemical resistance.
  • Use with sand and salt water applications, as well as hydraulic oil, coolants, gasoline and petroleum products.
  • Made in the USA
Part Name Item # Adapter
Size		 Thread
(Female NPT)		 Overall
Length
(C)		 Inside
Diameter
(E)		 Across
Corners
(F)		 Chain Lug
Extension
(G)		 Engagement
Length		 Max. Allowable
Working Press.
(PSI)*		 Weight
E05A 2000101 1/2" 1/2" 1.60" 0.53" 1.12" - 1.03" 250 PSI 0.055 lbs.
1/2A 2000105 3/4" 1/2" 1.62" 0.66" 1.49" - 0.97" 250 PSI 0.12 lbs.
07A 2000107 3/4" 3/4" 1.62" 0.75" 1.49" - 0.97" 250 PSI 0.09 lbs.
10A 2000110 1" 1" 1.91" 0.88" 1.76" 0.34 1.19" 250 PSI 0.165 lbs.
12A 2000112 1-1/4" 1-1/4" 2.16" 1.04" 2.19" 0.34" 1.44" 250 PSI 0.26 lbs.
15A 2000115 1-1/2" 1-1/2" 2.29" 1.35" 2.44" 0.33" 1.48" 250 PSI 0.32 lbs.
20A 2000120 2" 2" 2.54" 1.72" 2.92" 0.31" 1.75" 250 PSI 0.435 lbs.
25A 2000125 2-1/2" 2-1/2" 2.75" 2.14" 3.49" 0.27" 1.75" 200 PSI 0.61 lbs.
30A 2000130 3" 3" 2.84" 2.80" 4.22" 0.44" 1.84" 200 PSI 0.81 lbs.
40A 2000140 4" 4" 3.16" 3.78" 5.41" 0.39" 1.87" 150 PSI 1.505 lbs.
50A 2000150 5" 5" 3.22" 4.79" 6.49" 0.35" 1.97" 75 PSI 1.86 lbs.
60A 2000160 6" 6" 3.35" 5.90" 7.70" 0.60" 2.19" 75 PSI 2.49 lbs.

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
