1X2 3284H by Couplamatic | Hydraulic Return Line Hose | Two Fiber Braid | Red | 1" ID | 450ft
Package Quantity: 450 FT
Buy more, save moreDiscounts applied in cart/checkout.
Return Line Hose — Red
3284H Hydraulic Return Line Hose
Two fiber braid low pressure hose with a red rubber cover, built for hydraulic return and case drain lines where the red cover marks the low pressure side of the circuit.
1
What is this hose used for?
- Hydraulic Return Line
2
What are the key specifications?
Cover
Rubber (Red)
Reinforcement
Two Fiber Braid
Temperature
-40°F to +200°F (-40 to +96°C)
Size Range
1/2" to 1-1/2"
3
What are the main product features?
- Red cover — visually distinguishes return lines from pressure lines.
- Two fiber braids — flexible construction sized for return line pressures.
- Rubber cover — resists abrasion and weathering in equipment service.
4
Which sizes are available?
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/2X2 3284H | 1/2" | 0.875" | 300 lbs. | — | 7.5" | 24 lbs. | 500ft |
| 3/4X2 3284H | 3/4" | 1.156" | 300 lbs. | — | 11.5" | 41 lbs. | 500ft |
| 1X2 3284H | 1" | 1.437" | 300 lbs. | — | 14" | 62 lbs. | 450ft |
| 1-1/4X2 3284H | 1-1/4" | 1.781" | 250 lbs. | — | 18.5" | 84 lbs. | 400ft |
| 1-1/2X2 3284H | 1-1/2" | 2.031" | 250 lbs. | — | 22" | 104 lbs. | 300ft |
Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
Additional Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Compatible Series:
