1WAYBV300SW by Dixon Valve MannTek | Full Flow Ball Valve | One-Way | 3" Socket Weld End x 3" Socket Weld End | Aluminum

1WAYBV300SW by Dixon Valve MannTek | Full Flow Ball Valve | One-Way | 3" Socket Weld End x 3" Socket Weld End | Aluminum

Sale price$759.15

Dixon Valve & Coupling
MannTek Full Flow Ball Valve | One-Way | Aluminum
Buy More, Save More!
Quantity Price Each
5–14 $713.60
15–29 $645.28
30+ $569.36
Discounts applied in cart/checkout.

Product Data:

Brand:
  • MannTek
Shape:

Straight

Ends Configuration:
  • 3in Socket Weld End
  • 3in Socket Weld End
  • Some Ends Match
Features:
  • Two ports - one inlet and one outlet.
  • High flow rate; low pressure drop.
  • Spindle can be disassembled even when ball valve is installed.
Materials:
  • Wetted parts are aluminum and stainless steel.
  • FPM seals.
Specifications:
  • Working pressure: 150 PSI at ambient temperature 70°F (21°C).
  • Standard valve ports - female NPT, socket weld for Schedule 40 pipe and grooved.
Part Number End Type Size Bore
1WAYBV200 Female NPT x Female NPT 2" -
1WAYBV300 Female NPT x Female NPT 3" -
1WAYBV400 Female NPT x Female NPT 4" -
1WAYBV200SW Socket Weld End x Socket Weld End 2" 2.390"
1WAYBV300SW Socket Weld End x Socket Weld End 3" 3.530"
1WAYBV200VIC Grooved End x Grooved End 2" -
1WAYBV300VIC Grooved End x Grooved End 3" -

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
