Quality: |
- 24h 100% seal test guaranteed
- Dual sealing system allows valve to be operated in either direction making installation easier
- No metal-to-metal moving parts
- No maintenance ever required
- Handle clearly shows ball position
- Silicone-free lubricant on all seals
- Handle stops on body to avoid stresses at stem
- Chrome plated brass ball for longer life
|
|
Body: |
- Hot forged sand blasted, unplated brass body and cap sealed with Loctite® or equivalent thread sealant
- Finest brass according to EN 12165 and EN 12164 (formerly DIN 17660 and UNI 5705-65) specifications
|
|
Stem: |
- Blowout-proof nickel plated brass stem
- Two FPM O-rings at the stem for maximum safety
|
|
Sealing: |
- Pure PTFE self-lubricating seats with flexible-lip design
|
|
Threads: |
- NPT taper ANSI B.1.20.1 female by female threads
|
|
Flow: |
- Standard port for compact design
|
|
Handle: |
- Aluminum T-handle enameled red
- Handle removable with valve in service
- WARNING: do not exceed reasonable temperature and/or electrical load
|
|
Working Pressure & Temperature: |
- Maximum working pressure 600 PSI (CWP)
- -40°F/+350°F
- WARNING: freezing of the fluid in the installation may severely damage the valve
|
|
Approved by or in Compliance with: |
- Canadian standards Association (United States, Canada)
- GOST-R (Russia)
- Hygiene and epidemic center in Moscow city (Russia)
- RoHS Complaint (Russia)
- Underwriters Laboratories (United States & Canada)
- Meeting WW-V-35C Federal U.S. Specification
- NOTE: approvals apply to specific configurations/sizes only.
|
|
| Part Number |
Size |
Dimensions (Inches) |
| D |
DN |
I |
L |
G |
A |
H |
CH |
| 195C41 |
3/8" |
3/8" |
0.393" |
0.472" |
1.772" |
0.886" |
1.299" |
1.437" |
0.787" |
| 195D41 |
1/2" |
1/2" |
0.453" |
0.610" |
2.126" |
1.043" |
1.299" |
1.535" |
0.984" |
| 195E41 |
3/4" |
3/4" |
0.590" |
0.669" |
2.441" |
1.220" |
1.299" |
1.614" |
1.220" |
| 195F41 |
1" |
1" |
0.787" |
0.827" |
2.835" |
1.417" |
1.299" |
1.752" |
1.496" |
*DN shows the nominal flow diameter.
