1800260 (60B) by PT-Coupling | Cam & Groove Adapter | Type B | 6" Coupler x 6" Male NPT | Ductile Iron | Buna-N Seal

1800260 (60B) by PT-Coupling | Cam & Groove Adapter | Type B | 6" Coupler x 6" Male NPT | Ductile Iron | Buna-N Seal

Sale price$187.14

PT Coupling
Cam and Groove (Camlock) Adapter | Type B | Coupler x Male NPT Thread | Ductile Iron

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Buy More, Save More!
Quantity Price Each
5–19 $175.91
20–59 $159.07
60+ $140.36
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Cam & Groove Type:

Type B

Ends Configuration:
  • 6in Female Cam & Groove
  • 6in Male NPT
Overview:
  • PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
  • 8, 10, and 12 inch couplers have a 4-cam design with the STA-LOK® positive locking feature.
  • Excellent abrasion and wear resistance. Good strength and toughness characteristics.
  • Ideal for use with sand, grout, cement, and other abrasives.
  • Made in the USA
Part Name Item # Coupler
Size		 Thread
(Male NPT)		 O.D. with
Cam Arms
Extended
(A)		 Outside
Diameter
(B)		 Overall
Length
(C)		 Exposed
Length
(D)		 Inside
Diameter
(E)		 Engagement
Length		 Max. Allowable
Working Press.
(PSI)*		 Weight
E05B 1800201 1/2" 1/2" 4.21" 1.82" 2.10" 1.25" 0.56" 1.03" 250 PSI 0.385 lbs.
07B 1800207 3/4" 3/4" 4.51" 2.11" 2.10" 1.25" 0.78" 0.97" 250 PSI 0.505 lbs.
10B 1800210 1" 1" 5.10" 2.44" 2.50" 1.56" 0.97" 1.19" 250 PSI 0.734 lbs.
12B 1800212 1-1/4" 1-1/4" 6.86" 3.26" 2.89" 1.84" 1.25" 1.44" 250 PSI 1.311 lbs.
15B 1800215 1-1/2" 1-1/2" 7.16" 3.56" 2.93" 1.88" 1.50" 1.48" 250 PSI 1.564 lbs.
20B 1800220 2" 2" 7.54" 3.94" 3.20" 2.15" 1.88" 1.75" 250 PSI 2.065 lbs.
25B 1800225 2-1/2" 2-1/2" 8.03" 4.43" 3.63" 2.18" 2.38" 1.75" 200 PSI 2.66 lbs.
30B 1800230 3" 3" 9.56" 5.46" 3.82" 2.27" 2.88" 1.84" 200 PSI 4.207 lbs.
40B 1800240 4" 4" 10.66" 6.56" 4.00" 2.34" 3.60" 1.87" 150 PSI 5.962 lbs.
50B 1800250 5" 5" 11.67" 7.57" 4.20" 2.44" 4.50" 1.97" 75 PSI 7.392 lbs.
60B 1800260 6" 6" 16.26" 10.16" 4.52" 2.62" 5.60" 2.19" 75 PSI 11.9 lbs.

**8, 10, and 12 inch couplers have a 4-cam design with the STA-LOK® positive locking feature.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
