1641X6 by Danfoss | SelfAlign Adapter | Union Tee | Long Nut | 3/8" Tube OD x 5/16" Tube OD x 5/16" Tube OD | Brass

1641X6 by Danfoss | SelfAlign Adapter | Union Tee | Long Nut | 3/8" Tube OD x 5/16" Tube OD x 5/16" Tube OD | Brass

Sale price$13.34

Aeroquip® by Danfoss
SelfAlign Adapter - Union Tee (with Long Nut)
SelfAlign End x SelfAlign End x SelfAlign End
Buy More, Save More!
Quantity Price Each
10–39 $12.54
40–79 $11.34
80+ $10.01
Discounts applied in cart/checkout.

Product Data:

Material(s):
  • Brass
Applications:
  • Instrumentation, hydraulic and pneumatic systems.
Advantages:
  • Very low cost and reusable.
  • Self aligning - no need to disassemble fitting to line up sleeve on tube.
  • Low cost.
  • Easy to assemble, no flaring.
  • Good vibration resistance - use long nut when greater vibration resistance is needed.
Used With:
  • Aluminum, copper and plastic tubing.
  • Plastic tubing, except for PT230 and TP160, requires 2030x insert.
  • Not recommended for steel tubing.
Material:
  • CA360 Brass
Pressure:
  • Working pressure up to 2000 psi with a 4:1 safety factor depending on tube size.
  • When using plastic tubing, use the working pressure for type used.
Temperature Range:
  • -65°F to +250°F (-53°C to +121°C) with metal tubing.
  • When using compatible plastic tubing do not exceed the tubing temperature range.
Conformance:
  • An exclusive product design, user approvals only
Brass
Part Number		 Tube O.D. D M
1641X6 3/8" 0.312" 0.73"

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.

Explore Danfoss (Eaton - Aeroquip)
