1400315 (15C) by PT-Coupling | Cam & Groove Fitting | Type C | 1-1/2" Coupler x 1-1/2" Hose Shank | 316 Stainless Steel | Buna-N Seal

1400315 (15C) by PT-Coupling | Cam & Groove Fitting | Type C | 1-1/2" Coupler x 1-1/2" Hose Shank | 316 Stainless Steel | Buna-N Seal

Sale price$80.13

PT Coupling
Cam and Groove (Camlock) Fitting | Type C | Coupler x Hose Shank | 316 Stainless Steel | Buna-N Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Buy More, Save More!
Quantity Price Each
5–19 $75.32
20–59 $68.11
60+ $60.10
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Cam & Groove Type:

Type C

Ends Configuration:
  • 1-1/2in Female Cam & Groove
  • 1-1/2in Hose Barb
Overview:
  • PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
  • PT's specially designed multi-barbed shank with interlocking ring allows for attachment via original PUNCH-LOK® center punch clamps, or by an interlocked PROGRIP™ C-50 ferrule or sleeve.
  • 8, 10 and 12 in. couplers are 4-cam designs with the STA-LOK® positive locking feature.
  • Excellent corrosion-resistant material that provides high strength at high temperatures, helps prevent contamination of product being transported, maintains cleanliness and retains a lustrous appearance. Harder than brass.
  • Ideal for use with salt water, waste water, and many chemicals; can also be used with hydraulic oil and coolants.
  • Made in the USA
Part
Name		 Item # Coupler
Size		 Hose
Shank
Size		 O.D. with
Cam Arms
Extended
(A)		 Outside
Diameter
(B)		 Overall
Length
(C)		 Exposed
Length
(D)		 Inside
Diameter
(E)		 Min.
Inside
Diameter
(E)		 Engagement
Length		 Max. Allowable
Working Press.
(PSI)*		 Weight
E05C 1400301 1/2" 1/2" 4.21" 1.82" 2.69" 1.25" 0.38" 0.33" 1.03" 250 PSI 0.365 lbs.
07C 1400307 3/4" 3/4" 4.51" 2.11" 3.55" 1.25" 0.53" 0.40" 0.97" 250 PSI 0.64 lbs.
10C 1400310 1" 1" 5.10" 2.44" 4.06" 1.56" 0.78" 0.69" 1.19" 250 PSI 0.849 lbs.
12C 1400312 1-1/4" 1-1/4" 6.86" 3.26" 4.44" 1.84" 0.97" 0.88" 1.44" 250 PSI 1.685 lbs.
15C 1400315 1-1/2" 1-1/2" 7.16" 3.56" 4.82" 1.88" 1.22" 1.15" 1.48" 250 PSI 2.525 lbs.
20C 1400320 2" 2" 7.54" 3.94" 5.53" 2.15" 1.71" 1.60" 1.75" 250 PSI 2.428 lbs.
25C 1400325 2-1/2" 2-1/2" 8.03" 4.43" 5.93" 2.18" 2.16" 2.06" 1.75" 200 PSI 3.358 lbs.
30C 1400330 3" 3" 9.56" 5.46" 6.32" 2.27" 2.65" 2.55" 1.84" 200 PSI 4.907 lbs.
40C 1400340 4" 4" 10.66" 6.56" 6.64" 2.34" 3.53" 3.43" 1.87" 150 PSI 7.492 lbs.
50C 1400350 5" 5" 11.67" 7.57" 7.24" 2.44" 4.53" 4.43" 1.97" 75 PSI 10.381 lbs.
60C 1400360 6" 6" 16.26" 10.16" 9.50" 2.70" 5.53" 5.43" 2.19" 75 PSI 20.35 lbs.
80C 1400380** 8" 8" 18.23" 12.13" 9.50" 2.72" 7.53" 7.38" 2.15" 50 PSI 23.605 lbs.
100C 1400390** 10" 10" 20.66" 14.56" 12.00" 3.20" 9.40" 9.20" 2.55" 50 PSI 50.070 lbs.

** 8, 10 and 12 in. couplers are 4-cam designs with the STA-LOK® positive locking feature.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
