BS107 - #107 Beltservice E8/2 0/V5 White NA FDA Conveyor Belt

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Features:
No. 102 offers a limited release plus stain and abrasion resistance; ideal for baking, candy, and frozen foods - not for animal fats or harsh chemicals. No. 107 is a heavier version of No. 102 for more demanding applications. No. 107ASQ has a quiet weave antistatic bottom fabric that makes it an ideal choice for low noise applications. No. 107ASB is used in light duty industrial conveying.

	E5/1 0/V5 White NA FDA Pt No.: 102	E8/2 0/V5 White NA FDA Pt No.: 107	E10/2 0/V5 QW White AS FDA Pt No.: 107ASQ	E12/2 0/V5 Black AS Pt No.: 107ASB
Thickness	.040"	.078"	N/A	N/A
Covers	C x B	C x B	N/A	N/A
Carcass	Mono/Multi	Mono/Multi	N/A	N/A
Working Tension per Inch Width	28 lbs.	67 lbs.	N/A	N/A
Approx. Weight Lbs. Per Inch Width	.021"	.023"	N/A	N/A
Min. Pulley Diameter	1-3/16"	2"	N/A	N/A
Temperature Range	10 deg. F / 180 deg. F		N/A	N/A
Coefficient of Friction	.15	.15	N/A	N/A
Anti-Static	No	No	Yes	Yes
Clipper Lace	#25	#36	N/A	N/A

AS = Anti-Static
Mono = Monofilament
Multi = Multifilament
