1000120 (20A) by PT-Coupling | Cam & Groove Adapter | Type A | 2" Adapter x 2" Female NPT | Aluminum

1000120 (20A) by PT-Coupling | Cam & Groove Adapter | Type A | 2" Adapter x 2" Female NPT | Aluminum

Sale price$21.40

PT Coupling
Cam and Groove (Camlock) Adapter | Type A | Adapter x Female NPT Thread | Aluminum

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Buy More, Save More!
Quantity Price Each
10–39 $20.12
40–79 $18.19
80+ $16.05
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Cam & Groove Type:

Type A

Ends Configuration:
  • 2in Male Cam & Groove
  • 2in Female NPT
Overview:
  • PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
  • Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance.
  • Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
  • Made in the USA
Part Name Item # Adapter
Size		 Thread
(Female NPT)		 Overall
Length
(C)		 Inside
Diameter
(E)		 Across
Corners
(F)		 Chain Lug
Extension
(G)		 Engagement
Length		 Max. Allowable
Working Press.
(PSI)*		 Weight
E05A 1000101 1/2" 1/2" 1.60" 0.53" 1.12" - 1.03" 250 PSI 0.055 lbs.
1/2A 1000105 3/4" 1/2" 1.62" 0.66" 1.49" - 0.97" 250 PSI 0.12 lbs.
07A 1000107 3/4" 3/4" 1.62" 0.75" 1.49" - 0.97" 250 PSI 0.09 lb.
10A 1000110 1" 1" 1.91" 0.88" 1.76" 0.34" 1.19" 250 PSI 0.165 lb.
12A 1000112 1-1/4" 1-1/4" 2.16" 1.04" 2.19" 0.34" 1.44" 250 PSI 0.26 lbs.
15A 1000115 1-1/2" 1-1/2" 2.29" 1.35" 2.44" 0.33" 1.48" 250 PSI 0.32 lbs.
20A 1000120 2" 2" 2.54" 1.72" 2.92" 0.31" 1.75" 250 PSI 0.435 lbs.
25A 1000125 2-1/2" 2-1/2" 2.75" 2.14" 3.49" 0.27" 1.75" 200 PSI 0.61 lbs.
30A 1000130 3" 3" 2.84" 2.80" 4.22" 0.44" 1.84" 200 PSI 0.81 lbs.
40A 1000140 4" 4" 3.16" 3.78" 5.41" 0.39" 1.87" 150 PSI 1.505 lbs.
50A 1000150 5" 5" 3.22" 4.79" 6.49" 0.35" 1.97 75 PSI 1.86 lbs.
60A 1000160 6" 6" 3.35" 5.90" 7.70" 0.60" 2.19" 75 PSI 2.49 lbs.
80A 1000180 8" 8" 4.50" 7.80" 10.23" 0.60" 2.15 50 PSI 5.575 lbs.
100A 1000190 10" 10" 4.50" 10.10" 12.79" 0.60" 2.55" 50 PSI 9.06 lbs.
120A 1000192 12" 12" 4.38" 12.00". 14.75" - 2.55" 50 PSI 10 lbs.

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
