1" HPI by Couplamatic | Domestic HY-PLUS I One Wire Dimension Hi-Pressure Extremely Flexible Hydraulic Hose | SAE 100R17 | 1" ID | 250ft
Couplamatic Systems Inc.
One or Two Wire Braids Hoses - HPI Domestic HY-PLUS I One Wire Dimension Hi-Pressure Extremely Flexible Hydraulic Hose - (SAE 100R17)
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $2,904.03 |
| 8–14 | $2,780.45 |
| 15+ | $2,471.51 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
3000
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R17 |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | One or Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" HPI | 1/4" | 0.535" | 3,000 lbs. | 12,000 lbs. | 2" | 16 lbs. | 250ft |
| 3/8" HPI | 3/8" | 0.690" | 3,000 lbs. | 12,000 lbs. | 2.5" | 23 lbs. | 250ft |
| 1/2" HPI | 1/2" | 0.813" | 3,000 lbs. | 12,000 lbs. | 3.5" | 29 lbs. | 250ft |
| 3/4" HPI | 3/4" | 1.100" | 3,000 lbs. | 12,000 lbs. | 5" | 55 lbs. | 250ft |
| 1" HPI | 1" | 1.410" | 3,000 lbs. | 12,000 lbs. | 6" | 82 lbs. | 250ft |
*3000 PSI working pressure can eliminate stocking two hoses. Higher Pressure and More Flexible than 100R1*
