1" DH16 by Couplamatic | DURA-HYD Abrasion Resistant | Extra Hi-Pressure Hydraulic Hose | SAE 100R16/2SC | 1" ID | 200ft
Couplamatic Systems Inc.
Two Wire Braid Hoses - DH16 DURA-HYD Abrasion Resistant Extra Hi-Pressure Hydraulic Hose -(SAE 100R16/2SC)
Package Quantity: 200 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $1,338.50 |
| 8–14 | $1,281.55 |
| 15+ | $1,139.15 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
2500
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R16/2SC |
|---|---|---|---|
| Cover: | Flame Resistant, Extra Abrasion Resistant, MSHA approved. | Reinforcement: | Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" DH16 | 1/4" | 0.530" | 5,800 lbs. | 23,200 lbs. | 2" | 18 lbs. | 500ft |
| 3/8" DH16 | 3/8" | 0.687" | 5,000 lbs. | 20,000 lbs. | 2.5" | 27 lbs. | 400ft |
| 1/2" DH16 | 1/2" | 0.812" | 4,250 lbs. | 17,000 lbs. | 3.5" | 35 lbs. | 300ft |
| 5/8" DH16 | 5/8" | 0.937" | 3,625 lbs. | 14,500 lbs. | 4" | 40 lbs. | 250ft |
| 3/4" DH16 | 3/4" | 1.090" | 3,125 lbs. | 12,500 lbs. | 4.8" | 54 lbs. | 250ft |
| 1" DH16 | 1" | 1.405" | 2,500 lbs. | 10,000 lbs. | 6" | 74 lbs. | 200ft |
