1" 57MB-2 by Couplamatic | Domestic Thin Cover | 2-Wire Hydraulic Hose | SAE 100R2AT | 1" ID | 250ft
Couplamatic Systems Inc.
Two Wire Braid Hoses - 57MB-2 Domestic Thin Cover 2-Wire Hydraulic Hose - SAE 100R2AT
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $2,786.12 |
| 8–14 | $2,667.56 |
| 15+ | $2,371.17 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
2000
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R2AT |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" 57MB-2 | 1/4" | 0.593" | 5,000 lbs. | 20,000 lbs. | 4" | 24 lbs. | 250ft |
| 3/8" 57MB-2 | 3/8" | 0.750" | 4,000 lbs. | 16,000 lbs. | 5" | 34 lbs. | 250ft |
| 1/2" 57MB-2 | 1/2" | 0.875" | 3,500 lbs. | 14,000 lbs. | 7" | 43 lbs. | 250ft |
| 5/8" 57MB-2 | 5/8" | 1.010" | 2,750 lbs. | 11,000 lbs. | 8" | 51 lbs. | 250ft |
| 3/4" 57MB-2 | 3/4" | 1.158" | 2,250 lbs. | 9,000 lbs. | 9.5" | 61 lbs. | 250ft |
| 1" 57MB-2 | 1" | 1.500" | 2,000 lbs. | 8,000 lbs. | 12" | 88 lbs. | 250ft |
