1/4" H7 by Couplamatic | Braid Reinforced Hydraulic Hose | SAE 100R7 | 1/4" ID | Thermoplastic | Polyester | 250ft
Couplamatic Systems Inc.
Polyester Braid - H7 Thermoplastic Hydraulic Hose - (SAE 100R7)
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $436.17 |
| 15–29 | $394.41 |
| 30+ | $348.01 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
2750
Tubing Construction:
Cover Construction:
Specifications and Approvals:
Compatible Series:
| Applications: | Medium Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R7 |
|---|---|---|---|
| Cover: | Black Polyurethane, Perforated | Tube: | Nylon |
| Reinforcement: | Polyester Braid | Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/8" H7 | 1/8" | 0.325" | 3,000 lbs. | 12,000 lbs. | 0.5" | 3 lbs. | 250ft |
| 3/16" H7 | 3/16" | 0.433" | 3,000 lbs. | 12,000 lbs. | 0.75" | 4.9 lbs. | 250ft |
| 1/4" H7 | 1/4" | 0.508" | 2,750 lbs. | 11,000 lbs. | 1.5" | 6 lbs. | 250ft |
| 5/16" H7 | 5/16" | 0.585" | 2,500 lbs. | 10,000 lbs. | 1.75" | 7.5 lbs. | 250ft |
| 3/8" H7 | 3/8" | 0.650" | 2,250 lbs. | 9,000 lbs. | 2" | 10 lbs. | 250ft |
| 1/2" H7 | 1/2" | 0.815" | 2,000 lbs. | 8,000 lbs. | 3" | 15.6 lbs. | 250ft |
| 3/4" H7 | 3/4" | 1.062" | 1,250 lbs. | 5,000 lbs. | 6.5" | 19 lbs. | 100ft |
| 1" H7 | 1" | 1.335" | 1,000 lbs. | 4,000 lbs. | 8" | 27 lbs. | 100ft |
