1/2X2 3284H by Couplamatic | Hydraulic Return Line Hose | Two Fiber Braid | Red | 1/2" ID | 500ft
Couplamatic Inc
Two Fiber Braid - 3284H Hydraulic Return Line Hose
Package Quantity: 500 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $1,715.18 |
| 8–14 | $1,642.19 |
| 15+ | $1,459.73 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Compatible Series:
| Applications: | Hydraulic Return Line | SAE Rating: | N/A |
|---|---|---|---|
| Cover: | Rubber (Red) | Reinforcement: | Two Fiber Braid |
| Temperature: | -40F to +200F (-40 to +96C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/2X2 3284H | 1/2" | 0.875" | 300 lbs. | - | 7.5" | 24 lbs. | 500ft |
| 3/4X2 3284H | 3/4" | 1.156" | 300 lbs. | - | 11.5" | 41 lbs. | 500ft |
| 1X2 3284H | 1" | 1.437" | 300 lbs. | - | 14" | 62 lbs. | 450ft |
| 1-1/4X2 3284H | 1-1/4" | 1.781" | 250 lbs. | - | 18.5" | 84 lbs. | 400ft |
| 1-1/2X2 3284H | 1-1/2" | 2.031" | 250 lbs. | - | 22" | 104 lbs. | 300ft |
