1" 2SK by Couplamatic | Import Thin Cover | 2-Wire Extreme Pressure Hydraulic Hose | Exceeds 2SN/2SC | 1" ID | 200ft
Couplamatic Systems Inc.
Two Wire Braid Hoses - 2SN Import Thin Cover 2-Wire Hydraulic Hose - SAE 100R2AT/2SN
Package Quantity: 200 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $1,494.92 |
| 8–14 | $1,431.31 |
| 15+ | $1,272.27 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
3250
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | Rating: | Exceeds 2SN/2SC |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" 2SK | 1/4" | 0.520" | 6,530 lbs. | 26,120 lbs. | 2.0" | 24 lbs. | 500ft |
| 3/8" 2SK | 3/8" | 0.687" | 5,585 lbs. | 22,340 lbs. | 3.0" | 34 lbs. | 400ft |
| 1/2" 2SK | 1/2" | 0.810" | 5,000 lbs. | 20,000 lbs. | 3.6" | 43 lbs. | 300ft |
| 5/8" 2SK | 5/8" | 0.980" | 4,625 lbs. | 18,500 lbs. | 4.0" | 51 lbs. | 250ft |
| 3/4" 2SK | 3/4" | 1.155" | 4,350 lbs. | 17,400 lbs. | 5.0" | 61 lbs. | 250ft |
| 1" 2SK | 1" | 1.410" | 3,250 lbs. | 13,000 lbs. | 6.5" | 94 lbs. | 200ft |
| 1-1/4" 2SK | 1-1/4" | 1.715" | 2,500 lbs. | 10,000 lbs. | 12.0" | 130 lbs. | Bulk |
