0661 10 18 by Parker | Slide Valve | 3/8" Female NPT Thread with .39" Male | 3.21" Length | 1.38" Width | 1.38" Height | Straight | Nickel Plated Brass

0661 10 18 by Parker | Slide Valve | 3/8" Female NPT Thread with .39" Male | 3.21" Length | 1.38" Width | 1.38" Height | Straight | Nickel Plated Brass

Sale price$40.28

by Parker Hannifin
Pneumatic Slide Valves:0661 Male to Female Slide Valve - NPT
Buy More, Save More!
Quantity Price Each
20–39 $37.86
40–79 $34.24
80+ $30.21
Discounts applied in cart/checkout.

Product Data:

Series:
  • 0661 Series
Shape:

Straight

Ends Configuration:
  • 3/8in Female NPT
  • .39in Male NPT
Product Features:
  • Lightweight due to use of aluminum
  • Nitrile Seals
  • Immediate identification of the venting system by the color (red)
  • Uni-directional use ensures the downstream circuit is vented
  • Operated in the plane of the tube
Markets:
  • Factory/Process Automation
  • Food Processing
  • Packaging
Applications:
  • Pneumatics
  • Conveyors
  • Packaging
  • Textile
  • Plastics Engineering
Pressure Range: Up to 230 PSI (15.8 bar)
Temperature Range: +15° to +175° F (-9.4° to +79.4° C)
Part Number C Diameter Nominal (DN) F G L WT. OZ.
0661 04 11 1/8" .16" .55" .98" 2.19" 2.47
0661 07 14 1/4" .27" .67" 1.18" 2.75" 4.59
0661 10 18 3/8" .39" .87" 1.38" 3.21" 7.59

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
