| Technical Characteristics: |
-
Compatible Fluids: Compressed air
-
Working Pressure: 0 to 10 bar
-
Working Temperature: Air: -15°C to +50°C
Dry Air: -20°C to +80°C
-
Tubes: Tubes and hoses
|
| Advantages: |
Basic & standard blowguns:
- In compliance with international noise and pressure regulations
- Swivel nozzles for directional jet
Safety blowguns:
- Meets OSHA or SUVA standards according to model and complies with:
- noise exposure requirements
- provisions relating to outlet pressure
- Energy-saving blowguns
- Limited flow for lower energy consumption
- Kits and nozzles: to ensure a suitable product
|
| Regulations: |
- RoHS
- PED
- REACH
- OSHA
-
Protection of design:
All designs and models of Parker Legris blowguns have been registered with the following numbers:
13 224 / 13 225 / 13 226
-
DI: 2003/10/CE
Regulation relating to exposure to noise, particularly with regard to risks to hearing. The noise level must be less than 87 dBA.
|
| Component Materials: |
-
Body: Technical Polymer
-
Connection: Nickel-Plated Brass
-
Nozzle:
- Aluminum (standard blowgun)
- Nickel-Plated Brass (Safety and other blowguns)
-
Trigger: Technical Polymer
|
|
|
| Part Number |
Diameter Nominal (DN) |
C |
F |
H |
H1 |
L |
L1 |
Kg |
| 0654 00 13 |
3 mm |
1/4" |
20 mm |
117 mm |
35 mm |
148 mm |
73 mm |
.189 Kg |
Nozzle: nickel-plated brass, NPT version available.
