0489 10 17 by Parker | Legris In-Line Exhaust Port Ball Valve | M5x0.8 Female Metric Thread x 3/8" Female BSPP Thread | 24 mm Hex (F) | 24 mm Hex (F1) | Tee | Nickel-Plated Brass | Pack of 2

0489 10 17 by Parker | Legris In-Line Exhaust Port Ball Valve | M5x0.8 Female Metric Thread x 3/8" Female BSPP Thread | 24 mm Hex (F) | 24 mm Hex (F1) | Tee | Nickel-Plated Brass | Pack of 2

Sale price$99.13

by Parker Hannifin
Universal Series:0489 3/2 In-Line Threaded Exhaust Port Ball Valve, Female BSPP and Metric Thread

Package Quantity: 2 Units

Buy More, Save More!
Quantity Price Each
20–29 $93.18
30–59 $84.26
60+ $74.35
Discounts applied in cart/checkout.

Product Data:

Series:
  • 0489 Series
Shape:

Tee

Material(s):
  • Nickel-Plated Brass
  • Rilsan Graphited
  • ZAMAK
Technical Characteristics:
  • Compatible Fluids: Compressed air
  • Working Pressure: Vacuum up to 40 bar, depending on the model
  • Working Temperature: -20°C to +80°C
    up to -40°C with no handle operation
Advantages:
  • Automatic seal wear compensation
  • Vacuum resistance
  • Ease of operation
  • Short, repositionable and exchangeable handles
Regulations:
  • RoHS
  • PED
  • REACH
Component Materials:
  • Body: Nickel-plated brass
  • Stem: NBR
  • Stem seal: NBR
  • Seat seal: Graphite-impregnated polyamide
  • Ball: Nickel-Plated Polished Brass
  • Locking Nut: Nickel-plated brass
  • Wear-compensation seal: NBR
  • Lever: Treated Zamak
  • Lever fixing screw: Zinc-Plated Steel
Part Number Diameter Nominal (DN) C1 C E F F1 H H1 H2 L L1 M T Kg
0489 07 13 7 mm M5x0.8 1/4" 12 mm 24 mm 24 mm 46 mm 43 mm 17 mm 59 mm 31 mm 69 mm 2 mm .270 Kg
0489 10 17 10 mm M5x0.8 3/8" 12 mm 24 mm 24 mm 46 mm 43 mm 17 mm 59 mm 31 mm 69 mm 2 mm .243 Kg
0489 13 21 13 mm 1/8" 1/2" 15 mm 27 mm 27 mm 47 mm 44 mm 24 mm 67 mm 34 mm 69 mm 2 mm .310 Kg
0489 18 27 18 mm 1/4" 3/4" 16.5 mm 32 mm 38 mm 63 mm 54 mm 33 mm 80 mm 39 mm 108 mm 2.5 mm .670 Kg
0489 23 34 23 mm 1/4" 1" 19 mm 41 mm 46 mm 67 mm 57 mm 37 mm 94 mm 47 mm 108 mm 3 mm 1.050 Kg

Maximum working pressure: 40 bar
