0472 06 13 by Parker | Legris In-Line Ball Valve | 1/4" Female BSPP Thread | 19 mm Hex | 69 mm Length | Straight | Nickel-Plated Brass | Pack of 5

0472 06 13 by Parker | Legris In-Line Ball Valve | 1/4" Female BSPP Thread | 19 mm Hex | 69 mm Length | Straight | Nickel-Plated Brass | Pack of 5

Sale price$280.14

by Parker Hannifin
Universal Series:0472 2/2 Right-Angled Ball Valve, Female BSPP Thread

Package Quantity: 5 Units

Buy More, Save More!
Quantity Price Each
5–14 $263.33
15–29 $238.12
30+ $210.11
Discounts applied in cart/checkout.

Product Data:

Series:
  • 0472 Series
Shape:

Straight

Ends Configuration:
  • 1/4in Female BSPP
  • 1/4in Female BSPP
  • Some Ends Match
Technical Characteristics:
  • Compatible Fluids: Compressed air
  • Working Pressure: Vacuum up to 40 bar, depending on the model
  • Working Temperature: -20°C to +80°C
    up to -40°C with no handle operation
Advantages:
  • Automatic seal wear compensation
  • Vacuum resistance
  • Ease of operation
  • Short, repositionable and exchangeable handles
Regulations:
  • RoHS
  • PED
  • REACH
Component Materials:
  • Body: Nickel-plated brass
  • Stem: NBR
  • Stem seal: NBR
  • Seat seal: Graphite-impregnated polyamide
  • Ball: Nickel-Plated Polished Brass
  • Locking Nut: Nickel-plated brass
  • Wear-compensation seal: NBR
  • Lever: Treated Zamak
  • Lever fixing screw: Zinc-Plated Steel
Part Number Diameter Nominal (DN) C E F H H1 H2 J L L1 M Kg
0472 04 10 4 mm 1/8" 8 mm 14 mm 35 mm 29 mm 18 mm 14 mm 34 mm 25 mm 48 mm .096 Kg
0472 06 13 6 mm 1/4" 12 mm 19 mm 38 mm 31 mm 24 mm 22 mm 38 mm 28 mm 48 mm .191 Kg
0472 09 17 9 mm 3/8" 12 mm 24 mm 45 mm 43 mm 27 mm 25 mm 46 mm 31 mm 69 mm .260 Kg
0472 12 21 12 mm 1/2" 15 mm 27 mm 47 mm 44 mm 33 mm 29 mm 49 mm 34 mm 69 mm .312 Kg
0472 18 27 18 mm 3/4" 16.5 mm 38 mm 59 mm 51 mm 40 mm 39 mm 60 mm 39 mm 108 mm .704 Kg

Maximum working pressure: 20 bar
