0437 23 34 by Parker | Legris In-Line Vented 3-Point Lockable Ball Valve | 1" Female BSPP Thread | 41 mm Hex (F) | 46 mm Hex (F1) | Straight | Nickel-Plated Brass | Pack of 2

0437 23 34 by Parker | Legris In-Line Vented 3-Point Lockable Ball Valve | 1" Female BSPP Thread | 41 mm Hex (F) | 46 mm Hex (F1) | Straight | Nickel-Plated Brass | Pack of 2

Sale price$569.11

by Parker Hannifin
Universal Series:0437 3/2 In-line Vented 3-Point Lockable Ball Valve, Female BSPP Thread

Package Quantity: 2 Units

Buy More, Save More!
Quantity Price Each
5–14 $534.96
15–29 $483.74
30+ $426.83
Discounts applied in cart/checkout.

Product Data:

Series:
  • 0437 Series
Shape:

Straight

Ends Configuration:
  • 1in Female BSPP
  • 1in Female BSPP
  • Some Ends Match
Technical Characteristics:
  • Compatible Fluids: Compressed air
  • Working Pressure: Vacuum up to 40 bar, depending on the model
  • Working Temperature: -20°C to +80°C
    up to -40°C with no handle operation
Advantages:
  • Automatic seal wear compensation
  • Vacuum resistance
  • Ease of operation
  • Short, repositionable and exchangeable handles
Regulations:
  • RoHS
  • PED
  • REACH
Component Materials:
  • Body: Nickel-plated brass
  • Stem: NBR
  • Stem seal: NBR
  • Seat seal: Graphite-impregnated polyamide
  • Ball: Nickel-Plated Polished Brass
  • Locking Nut: Nickel-plated brass
  • Wear-compensation seal: NBR
  • Lever: Treated Zamak
  • Lever fixing screw: Zinc-Plated Steel
Part Number Diameter Nominal (DN) C E F F1 H L L1 M T Kg
0437 07 13 7 mm 1/4" 12 mm 24 mm 24 mm 60 mm 59 mm 32 mm 69.5 mm 2 mm .476 Kg
0437 10 17 10 mm 3/8" 12 mm 24 mm 24 mm 60 mm 60 mm 32 mm 69.5 mm 2 mm .447 Kg
0437 13 21 13 mm 1/2" 15 mm 27 mm 27 mm 60 mm 67.5 mm 34.5 mm 69.5 mm 2 mm .510 Kg
0437 18 27 18 mm 3/4" 16.5 mm 32 mm 38 mm 69.5 mm 80 mm 39.5 mm 108.5 mm 2.5 mm .820 Kg
0437 23 34 23 mm 1" 19 mm 41 mm 46 mm 73 mm 94.5 mm 47.5 mm 108.5 mm 3 mm 1.192 Kg

Maximum working pressure: 40 bar
Handle is not removable
Locking plates are zinc-plated steel
