01VA03NO03N0601 by AIGNEP | 01V Control Valves Series | 3/2 Normally Open Single Solenoid Ext Pilot 1/4" NPTF | 220V AC/5VA coil | Black Con
01VA03NO03N0601 by AIGNEP | 01V Control Valves Series | 3/2 Normally Open Single Solenoid Ext Pilot 1/4" NPTF | 220V AC/5VA coil | Black Con
AIGNEP

01VA03NO03N0601 by AIGNEP | 01V Control Valves Series | 3/2 Normally Open Single Solenoid Ext Pilot 1/4" NPTF | 220V AC/5VA coil | Black Con

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

SOLENOID ASSISTED
Technical Characteristics:
Operating Rating: 0 ÷ 10 bar
0 ÷ 145 psi		 Operating Pressure: Monostable: 2 ÷ 10 bar / 29 ÷ 145 psi
Bistable: 1 ÷ 10 bar / 14.5 ÷ 145 psi
Temperature: Min: 14°F (-10°C)
Max: 140°F (60°C)		 Component Parts and Materials: • Anodised and painted aluminium body
• Chemical nickel-plated spool
• NBR seals
Part Number (Black Con) Part Number (LED Con) Solenoid Voltage Minimum Power Ways Reactuation Function Size
01VA03NO02N0101 01VA03NO02N0102 12V DC 3W 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO02N0201 01VA03NO02N0202 24V DC 3W 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO02N0301 01VA03NO02N0302 24V DC 2W 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO02N0401 01VA03NO02N0402 24V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO02N0501 01VA03NO02N0502 110V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO02N0601 01VA03NO02N0602 220V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/8" NPTF
01VA03NO03N0101 01VA03NO03N0102 12V DC 3W 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
01VA03NO03N0201 01VA03NO03N0202 24V DC 3W 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
01VA03NO03N0301 01VA03NO03N0302 24V DC 2W 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
01VA03NO03N0401 01VA03NO03N0402 24V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
01VA03NO03N0501 01VA03NO03N0502 110V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
01VA03NO03N0601 01VA03NO03N0602 220V AC 5VA 3/2 Monostable Spring Return Normally Opened (NO) 1/4" NPTF
