0118 05 10 39 by Parker | Legris Stud Fitting w/ Bi-Material Seal | 5 mm Tube Size x 1/8" Male BSPP Thread | 12 mm Hex | Banjo | Brass | Pack of 10

0118 05 10 39 by Parker | Legris Stud Fitting w/ Bi-Material Seal | 5 mm Tube Size x 1/8" Male BSPP Thread | 12 mm Hex | Banjo | Brass | Pack of 10

Sale price$191.14

by Parker Hannifin
Brass Compression Fittings / Stud Fittings:0118..39 Single Banjo with Bi-Material Seal, Male BSPP Thread

Package Quantity: 10 Units

Buy More, Save More!
Quantity Price Each
5–19 $179.67
20–59 $162.47
60+ $143.36
Discounts applied in cart/checkout.

Product Data:

Series:
  • 0118 Series
Shape:

Banjo

Ends Configuration:
  • 5mm Tube Compression
  • 1/8in Male BSPP
Technical Characteristics:
  • Compatible Fluids: Water, machining oil, fuel, hydraulic oil, compressed air, chemical fluids, disinfectants
  • Working Pressure: Vacuum to 550 bar
  • Working Temperature: -60°C to +250°C (without sealing washer, with metal tubing)
Advantages:
  • 22 configurations
  • Excellent sealing due to the tightening of the olive onto the tube
  • Metallic sealing for optimum service life, pressure, and temperature ranges
  • Connection of different types of tubing and hose: metal, polymer, steel, rubber, etc.
  • Multiple tube diameters can be connected using the Legris reducer assembly system
Regulations:
  • RoHS
  • PED
  • REACH
Component Materials:
Part Number ØD C F F1 H H1 L (max) L1 N Kg
0118 04 10 39 4 mm 1/8" 14 mm 10 mm 23 mm 9.5 mm 24 mm 14.5 mm 17.5 mm .040 Kg
0118 05 10 39 5 mm 1/8" 14 mm 12 mm 23 mm 9.5 mm 25 mm 14.5 mm 17.5 mm .042 Kg
0118 06 10 39 6 mm 1/8" 14 mm 13 mm 23 mm 9.5 mm 25 mm 14.5 mm 17.5 mm .043 Kg
0118 06 13 39 6 mm 1/4" 17 mm 13 mm 24 mm 10 mm 26 mm 16 mm 21 mm .058 Kg
0118 08 10 39 8 mm 1/8" 14 mm 14 mm 23 mm 9.5 mm 28 mm 15.5 mm 17.5 mm .055 Kg
0118 08 13 39 8 mm 1/4" 17 mm 14 mm 24 mm 10 mm 28 mm 28 mm 15.5 mm .21 Kg
0118 10 13 39 10 mm 1/8" 14 mm 10 mm 23 mm 9 mm 24 mm 14 mm 17 mm .040 Kg
0118 10 17 39 10 mm 3/8" 22 mm 19 mm 31.5 mm 13.5 mm 34 mm 19 mm 26.5 mm .128 Kg
0118 12 17 39 12 mm 3/8" 22 mm 22 mm 34.5 mm 15 mm 34 mm 19 mm 26.5 mm .0137 Kg
0118 14 17 39 14 mm 3/8" 22 mm 24 mm 37.5 mm 16.5 mm 37 mm 20.5 mm 28 mm .196 Kg
0118 14 21 39 14 mm 1/2" 27 mm 24 mm 39 mm 16.5 mm 38 mm 20.5 mm 32.5 mm .207 Kg
0118 15 21 39 15 mm 1/2" 27 mm 27 mm 40 mm 16.5 mm 38 mm 20.5 mm 32.5 mm .202 Kg
0118 22 27 39 22 mm 3/4" 32 mm 36 mm 54 mm 22.5 mm 45 mm 24.5 mm 39 mm .467 Kg

With bi-material sealing washer
The bi-material sealing washers, part number 0139, can be found in the sub-chapter “Adaptors and Manifolds”.
