GLBR5000 by Dixon Valve | Liquid Filled Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-5000 PSI Range | Brass

GLBR5000 by Dixon Valve | Liquid Filled Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-5000 PSI Range | Brass

Sale price$114.40

Dixon Valve
Dixon® Gauge | Liquid Filled Gauge | Lower Mount

Designed for long, reliable service under rugged conditions.

Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement.
Buy More, Save More!
Quantity Price Each
5–19 $107.54
20–59 $97.24
60+ $85.80
Discounts applied in cart/checkout.

Product Data:

Series:
  • GLBR Series
Features:
  • ± 2-1-2% accuracy on 2-1/2"; ±1% accuracy on 4".
  • Brass movement with highly polished bearing surfaces.
Materials:
  • Window: acrylic with membrane assembly.
  • Bourdon tube: copper alloy.
  • Glycerin filled.
  • 2-1/2" face gauges: solid cast brass case with polished ABS cover ring.
  • 4" face gauges: cast brass, silver painted case with chrome plated brass cover ring.
Specifications:
  • Ambient temperature range: -4°F to 140°F (-20°C to 60°C)
Term Meanings:
  • Figure Interval: Figure Interval (Increments between PSI numbers on gauge face).
  • Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).
2-1/2" Face
1/4" Lower Mount
Part Number		 2-1/2" Face
1/4" Center Back Mount
Part Number		 4" Face
1/2" Lower Mount
Part Number		 PSI Range Figure
Interval 		Minor
Gradient
GLBR15 GLBRC15 GLBR15-4 0-15 PSI 3 0.2
GLBR30 GLBRC30 GLBR30-4 0-30 PSI 5 0.5
GLBR60 GLBRC60 GLBR60-4 0-60 PSI 10 1
GLBR100 GLBRC100 GLBR100-4 0-100 PSI 10 1
GLBR160 GLBRC160 GLBR160-4 0-160 PSI 20 2
GLBR200 GLBRC200 GLBR200-4 0-200 PSI 20 2
GLBR300 GLBRC300 GLBR300-4 0-300 PSI 50 5
GLBR400 GLBRC400 GLBR400-4 0-400 PSI 50 5
GLBR600 GLBRC600 GLBR600-4 0-600 PSI 100 10
GLBR1000 GLBRC1000 GLBR1000-4 0-1000 PSI 100 10
GLBR1500 GLBRC1500 GLBR1500-4 0-1500 PSI 300 20
GLBR2000 GLBRC2000 GLBR2000-4 0-2000 PSI 200 20
GLBR3000 GLBRC3000 GLBR3000-4 0-3000 PSI 500 50
GLBR5000 GLBRC5000 GLBR5000-4 0-5000 PSI 500 50
- - GLBR100004 0-10000 PSI 1000 100
