150P-3 by Banjo | 1-1/2" Pump with 3.5 HP Briggs & Stratton® Engine | Gas Engine | Polypropylene

150P-3 by Banjo | 1-1/2" Pump with 3.5 HP Briggs & Stratton® Engine | Gas Engine | Polypropylene

Sale price$747.26

Banjo Self-Priming Centrifugal Pumps - 1-1/2" Polypropylene Pumps with Gas Engines & Replacement Parts
Buy More, Save More!
Quantity Price Each
5–14 $702.42
15–29 $635.17
30+ $560.45
Discounts applied in cart/checkout.

Product Data:

SPECIFICATIONS

Application: Fluids, Agriculture, Industrial
Product Manual: 1-1/2 & 2" Cast Iron & Stainless Steel Pump Instruction Manual PDF Video: N/A
Features:
  • Cast iron construction for rugged dependable service
  • Stainless steel shaft sleeve to protect engine shaft
  • Carbon ceramic seal with stainless steel cup and spring with FKM (viton type) rubber
  • Replaceable inlet and outlet flanges
  • Dynamically balanced impeller
  • Pump Only packs complete and ready for attachment to gasoline engine
  • Pedestal pump for long coupling to electric motor
Notes:
  • Important: Recommended horsepower, listed below, is for water only. Heavier fluids may require additional horsepower or a trimmed impeller
  • CAUTION-WARNING: Please do not run pump dry, restrict or reduce port sizes, or dead head pump. This could cause component failure to pump
  • Engine warranty service available at authorized Briggs & Stratton® and Honda® dealers.
  • DO NOT USE WITH FLAMMABLE LIQUIDS
Part Number Description Horsepower
1-1/2" Cast Iron Pumps with Gas Engines
150PI3V 1-1/2" Cast Iron Pump 3HP Briggs & Stratton® Engine - FKM Seals 3 HP N/A
150PI-3 1-1/2" Cast Iron Pump with 3.5 HP Briggs & Stratton® Engine 3.5 HP (Made to Order)
1-1/2" Cast Iron C-Flange Pumps
150POICF5/8-4.1 1-1/2" Cast Iron C-Flange Pump with 5.8" Shaft Sleeve* & 4.1 Impeller N/A (Made to Order)

* Recommendation for 5/8" Shaft: 56C Frame Size, 3 HP, 3450 RPM, & 5" Max Impeller for close coupling to electric motors. 7/8" Shaft: 145TC Frame Size, 3 HP, 3450 RPM, & 5" Max Impeller for close coupling to electric motors.

Replacement Parts for 1-1/2" Cast Iron Pumps
Item Part Number Description Quantity Required
1 17001 1-1/2" Threaded Outlet Flange 1
2 17003 1-1/2" Threaded Inlet Flange 1
3 17004 Adapter for Gas Engine 1
3 17046 C-Flange Adapter 1
4 17005 5/8" Sleeve Drive for Electric Motor 1
4 17006* 3/4" Sleeve Drive 1
4 17007 7/8" Sleeve Drive for Electric Motor 1
5 17008* 5" Impeller 1
5 17008-4.1* 4.1" Trimmed Impeller 1
6 17010 1/2" Hex Nut 1
7 17011* Wear Plate 1
8 17013 EPDM Gasket 1
9 17016 Check Valve Assembly 1
10 17018* Gasket Adapter 1
11 15022 1-1/2"-2" Handle 1
12 17023 5/8" Clamp for 3/4" Shaft Assembly (Old Style) 1
12 17123 5/8" Clamp for 3/4" Shaft Assembly (Keyed) 1
12 17024 7/8" Clamp for 3/4" Shaft Assembly 1
13 17026 2" Pump Housing 1
14 V10118 5/16" Lock Washer 18
15 V10119 5/16" - 18 SS Hex Nut 6
Not Shown 12882R Housing 1
Not Shown 12883R Bearing Pedestal with 3/4" Shaft Only 1
Not Shown 12883B Bearings 2
16 12882A Complete Pedestal Assembly 1
17 17040 5/16"-24 x 1.00" Cap Screw 4
18 17028* 2" EPDM Seal Assembly 1
18 17035* FKM (viton type) Seal Assembly 1
18 17035SD* 2" Severe Duty Seal 1
19 17042 1-1/4" X 5/16"-18-2A5A Stud 6
20 17019 5/16"-18 x 3/4" Cap Screw 8
21 17009B 5/8"-18 Impeller Nut 1
22 17130 5/16-18 x 1.00" FHSCS, 18-8 SS 2
23 12777 1/2" Plug 1
24 UV15163 1-1/2" O-Ring 1
Not Shown 17033 Z Rails (Pair) 1
Not Shown 17100 1-1/2" & 2" Repair Kit (Consists of items 4*, 5*, 7,10,18*) 1
